Dimensions of vases 2111 and 2110

Front-wheel drive station wagon

The first car of the VAZ-2111 model rolled off the assembly line of the Volzhsky Automobile Plant in 1998. He was a representative of the new front-wheel drive tenth model family, designed to replace outdated classic cars in the company's production line. It should be noted that the VAZ-2111 became the first serial domestic station wagon with front-wheel drive.

Another distinctive feature of the tenth family is the fact that the company’s designers developed several modifications at once, and therefore the technical characteristics of the VAZ-2111 are very similar to those of its classmates in the following version:

• sedan - 2110 (produced from 1997 to 2010);
• five-door hatchback – 2112 (1998-2011);
• three-door hatchback - 2123 (2002-2009).

The station wagon was produced at the Volzhsky Automobile Plant until the spring of 2011. Under the designation “Bogdan” the car was manufactured at the Cherkasy Automobile Plant (Ukraine) until 2014.

VAZ 2111 Eleventh technical specifications

Performance characteristics of the VAZ 2111 eleventh

Maximum speed: 160 km/h Acceleration time to 100 km/h: 15 sec Fuel consumption per 100 km in the city: 10 l Fuel consumption per 100 km on the highway: 5.7 l
Fuel consumption per 100 km in the combined cycle: 7.3 l Fuel tank volume: 43 l Vehicle curb weight: 1020 kg Permissible gross weight: 1520 kg Tire size: 175/65 R14
Engine characteristics

Location: front, transverse Engine capacity: 1596 cm3 Engine power: 90 hp Number of revolutions: 5000 Torque: 131/3700 ​​n*m Power system: Distributed injection Turbocharging: no Gas distribution mechanism: no Cylinder arrangement: In-line Number of cylinders: 4 Number of valves per cylinder: 4 Recommended fuel: AI-95 Environmental standard: EURO III

Brake system

Front brakes: Ventilated disc Rear brakes: Drum

Steering

Steering Type: Rack and Pinion Power Steering: No

Transmission

Drive: Front Number of gears: manual gearbox - 5 Gear ratio of the main pair: 3.7

Suspension

Front suspension: Shock absorber Rear suspension: Coil spring

Body

Body type: station wagon Number of doors: 5 Number of seats: 5 Vehicle length: 4285 mm Vehicle width: 1680 mm Vehicle height 1480 mm Wheelbase: 2492 mm Front track: 1400 mm Rear track: 1370 mm Ground clearance (clearance): 160 mm Maximum trunk volume: 1420 l Minimum trunk volume: 450 l

Production

Year of manufacture: from 1997 to 2009

Exterior and interior of the station wagon

Despite the fact that the Volzhsky Automobile Plant began developing its first generation of front-wheel drive cars back in the mid-eighties, the design of the VAZ-2111 at the beginning of production was considered quite interesting and differed significantly from the previous ninth generation of cars. The company's designers managed to create this appearance using the following solutions:

• narrow radiator grille;
• wide lower air intake;
• large combined head optics;
• tilt and stamping ribs of the hood;
• straight front lines of the body;
• top rails;
• enlarged rear lights with longitudinal insert;
• top spoiler with built-in brake light.

The car interior is different:

• straight center console;
• dashboard with a protective visor and additional control keys;
• two-spoke steering wheel;
• insert on the console with controls for climate control equipment and audio system.

The finishing uses soft plastic, fabric materials, and soft floor covering.

The front seats with headrests had several adjustment options, and the rear ones could be folded in a 2/3 ratio, which made it possible to transport long cargo inside.

VAZ-2111

VAZ-2111

The VAZ-2111 began production at the VAZ plant in 1998. The peculiarity of the car is that it is the first station wagon with front-wheel drive, not only within the VAZ model range, but also in Russia as a whole. The car is based on the base model of the VAZ-2110, the only differences are the rear part of the body and the rear suspension, all other components of the car are unified. The problems of creating the car were the same as with the VAZ-2110, but the tests were somewhat different, since the station wagon is designed to carry cargo in addition to passengers, the rear suspension and the reliability of the body as a whole were additionally tested. The problem was solved about what the back door should be and the shape of the rear part of the body in general - at what angle the door should be tilted. The back door was tested for the reliability of the locks, the absence of backlash and squeaks when moving. Glass was also a controversial subject; it was planned that the car would have a front window; there was also an option without a window, but with a front fixed part of the glass.

Ultimately, we came to the conclusion that the side front glass should be solid.

The car uses two engine options, both with a displacement of 1.5 liters. The first carburetor, which has a power of 76 hp. The second with distributor injection for each cylinder has a power of 94 hp. The second engine option allows the car to show excellent dynamic performance. Manufactured car modifications:

• LADA-21111 (VAZ-21111) - 1.5 liter engine with a carburetor;
• LADA-21110 (VAZ-21110) - 8-valve engine with a working volume of 1.5 liters with distributed fuel injection;
• LADA-21113 (VAZ-21113) - 16-valve engine with a working volume of 1.5 liters with distributed fuel injection;
• LADA-21112 (VAZ-21112) - 8-valve 1.6-liter engine 21114 with distributed fuel injection with a power of 80 hp;
• LADA-21114 (VAZ-21114) - 16-valve 1.6-liter engine 21124 with distributed fuel injection producing 89 hp.
• LADA-21116 (VAZ-21116-04) - 2.0-liter Opel C20XE engine with 150 hp, all-wheel drive.
• VAZ 2111-90 “Tarzan 2”

VAZ 2111-90 “Tarzan 2”

The car gained good popularity in Russia; the model was produced from 1998 to 2009. After 2009, the VAZ-2111 was produced at the Cherkassy bus plant and the KrAZ plant in the city of Kremenchug. These were already more advanced cars, they were distinguished by greater comfort and a range of large options. However, in 2014, production was practically discontinued due to well-known events.

Technical characteristics of the VAZ-2111 car:

• 0

4 637

Author: total-rating.ru

Print

Technical specifications

For the new station wagon, at the initial stage of production, the VAZ-2111 engine model with technical characteristics was considered the base one:

• type – four-stroke;
• fuel - gasoline (AI-92, AI-95);
• cooling – liquid;
• number of cylinders – 4;
• location – in-line;
• number of valves – 8;
• volume – 1.50 l;
• power – 78.0 l. With.;
• cylinder diameter - 8.20 cm;
• piston stroke – 7.10 cm.

The features of this power unit include a gasoline injection system for mixture formation.

Technical characteristics of the VAZ-2111 station wagon with the base engine are:

• passenger capacity – 5 people;
• number of doors – 5;
• trunk volume – 445 l (with the rear row of seats folded – 1425 l);
• total weight – 1.04 t;
• drive – front;
• Gearbox – mechanical (5-speed);
• wheelbase - 2.49 m;
• ground clearance - 16.0 cm;
• length – 4.29 m;
• width – 1.68 m;
• height – 1.40 m;
• turning radius – 5.20 m;
• maximum speed - 161 km/h;
• acceleration (100 km/h) – 14.0 sec;
• wheel size – 175/70R13.

Technical characteristics of the car VAZ 2111, VAZ 21111, VAZ 21113

BODY Trade name - 1.5 Li Body type - station wagon, 5-door Number of seats - 5 Length - 4285 mm Width - 1680 mm Height - 1460 mm Wheelbase - 2492 Front track - 1400 Rear track - 1370 Ground clearance: to the oil pan engine - 165 mm to the lowest point of the exhaust system - 140 mm Trunk volume - 750 dm3 General data Curb vehicle weight - 1020 kg Payload - 500 kg permissible total weight - 1520 kg gasoline consumption per 100 km: in the urban driving cycle - 9.1 l on the highway - 5.6 l combined cycle - 7.3 l fuel tank volume - 43 l smallest turning radius of the front wheel - 5.2 m maximum speed - 160 km/h vehicle acceleration time to 100 km/h - 15 s brake vehicle travel distance from a speed of 80 km/h on a horizontal section of an asphalt highway – 38 m maximum climbability without acceleration – 34% maximum weight of the roof rack – 50 kg weight of a towed trailer with brakes – 800 kg weight of a towed trailer without brakes – 400 kg Engine Engine location - front, transverse Engine volume - 1500 cm3 Cylinder type - in-line Number of cylinders - 4 Cylinder diameter and piston stroke - 82x71 mm Compression ratio - 9 Number of valves - 8 Power system - distributed injection Power - 76/5600 hp Torque - 118 /3000n*m Fuel - AI-95. Transmission Clutch drive - cable Gearbox - mechanical, 5-speed Main gear ratio - 3.7 or 3.9 Gear ratios: first - 3.6 second - 1.95 third - 1.36 fourth - 0, 94 fifth - 0.78 reverse - 3.5 Drive wheels - front Chassis Front suspension - MacPherson strut, shock absorber strut Rear suspension - trailing arm, coil spring Tire size - 175/70 SR13 Wheel size 5J x 13 Steering Steering - rack and pinion Brake system Front brakes - disc Rear brakes - drum Parking brake drive - cable Modification of VAZ 21111 - characteristic differences are: trade name - 1.5 power - 72/5600 hp torque - 106/3400 n*m power supply system - carburetor compression ratio - 9 fuel consumption: on the highway - 5.3 l/100 km in the city - 8.9 l/100 km Modification VAZ 21113 trade name - 1.5GLi 16V power - 94/5600 hp torque – 130/3600 n*m power system – distributed injection number of valves – 16 compression ratio – 9.5 fuel consumption: on the highway – 5.1 l/100 km in the city – 8.9 l/100 km

avtocar.net

Reviews about the car

Among the main advantages, in addition to the versatility and technical characteristics of the VAZ-2111, car owners note:

• interesting design;
• high-quality head optics;
• a significant number of power units;
• affordable price;
• comfortable interior;
• permeability;
• overall reliability.

The main disadvantages are:

• low quality paintwork;
• poor sound insulation;
• assembly defects.

Thanks to the station wagon body, affordable price and high-quality technical characteristics, the VAZ-2111 has become the longest-running modification of the tenth family of Volga small cars.

VAZ 21111 1.5: price, technical characteristics VAZ 21111 1.5

avto-russia.ru

Specifications

The VAZ 2111 engine, the technical characteristics of which are presented below, was developed for the Lada 2110-2112 series of vehicles. As a result, it turned out that the power unit is installed even on modern production models, such as Largus and Vesta. Possessing high performance, ease of maintenance and repair, it has become the heart of many car enthusiasts.

So, let's look at the technical characteristics and features of the 2111 engine:

It is worth noting that with relatively modest characteristics, the service life of the VAZ 2111 engine is 250,000 km, and with proper maintenance, it can reach 280,000 km.

VAZ 2111 / VAZ 2111

2111: parameters, tests (test drive, crash test), reviews, car dealerships, photos, videos, news.

VAZ 2111

- production began in 2004. The combination of style and technology 2111, created by VAZ, has proven itself in the market and is time-tested.
This station wagon is perfect for the head of a large family, lovers of outdoor activities or summer residents. The very name of the “station wagon” body speaks about how suitable this type is for everything. Among the existing basic colors of 2111 you can easily find one that suits you, but most likely you can choose it to order. We most likely do not have all the configurations of this VAZ 2111 model, among which there are various options for assembling the 2111: the gearbox can be automatic or manual, the interior is trimmed with leather or wood inserts, wheels and other additional body elements of the 2111, which will certainly be reflected in the price 2111. The technical characteristics are good, but do not forget about the safety of the 2111 or the engine size, which will then make itself felt in terms of operating costs in the future, as well as repairs of the 2111 and maintenance with a warranty period. Since the purchase is made not for several months, but for several years, therefore, consider for yourself what you will do in the summer and winter, what trips to make in 2111
. The table below shows a comparison of several configurations of the 2111, among the parameters are reflected: what are the overall dimensions of the 2111, what is the fuel consumption in the city, highway or mixed, engine size, maximum speed and acceleration time to 100 km/h, curb or gross weight of the 2111, wheelbase, front and rear wheel tracks, transmission type (gearbox/gearbox), what kind of drive, tire size, how much power or torque and what price. In addition to all the numbers, you can read reviews of car owners about the 2111, watch videos or news, tests (test drive, crash test).
